Home Refrigerator Ultra low temperature compact medical refrigerator

Ultra low temperature compact medical refrigerator

Ultra Low Temperature medical grade freezer inner tank is made of full-mirror stainless steel 304, which is free of pollution sources and easy to clean; it has an alarm system that meets GMP requirements; it has a data acquisition system that meets GMP requirements. It is equipped with a needle printer and U disk storage as standard. It is suitable for stability test and storage of temperature-sensitive drugs.


Temp.Range: -15℃~-25℃

Environment temperature: 5~35℃

Fluctuation: ±0.5℃

Deviation: ±2.0℃

Power:AC 220V±10% 50HZ

  • Item NO.:

    150FC~720FC
  • Product Origin:

    CHINA
  • PRODUCT OVERVIEW

  • PRODUCT SPECS

  • APPLICATION

Ultra low temperature compact medical freezer

XCH Biomedical Ultra Low Temperature Freezer, adopt the latest structural design, select the original imported high quality parts and manufacturing process, ensure the long-term continuous operation of the equipment, stable and reliable performance, suitable for temperature sensitive medicine stability test and preservation.


Key Features:


Materials:

The inner tank is made of full-mirror stainless steel 304, which has no pollution source and is easy to clean


With alarm system data acquisition system:
It has an alarm system that meets GMP requirements; it has a data acquisition system that meets GMP requirements, with a needle printer and U disk storage as standard


Safety device:

compressor overheating and overpressure and overload protection


Alarm system:

On-site temperature deviation sound and light alarm, standard remote mobile phone SMS alarm (with power failure alarm)


Attributes

Meet ICH2003, Pharmacopoeia 2020 edition, executive standard: GB/T 10586-2006
Temperature fluctuation degree:<±0.5℃

Temperature deviation: <±2.0℃;
Power supply: AC 220V±10% 50HZ

Ambient temperature: +5 ~ 35℃.


Model & Parameters:

MODEL

TEMP RANGE

CAPACITY

INTERNAL DIMEN(mm)

W×D×H

EXTERNAL DIMEN(mm)

W×D×H

POWER

TRAY

XCH-250MF

-20℃

250L

600×500×830

760×870×1650

1.5KW

3

XCH-400MF

-20℃

400L

600×700×950

760×1060×1750

2.0KW

3

Single door medical freezer


Cold Storage Stability Test:


Experimental project
Experimental conditions
Sampling time
Shortest experimental period
Long-term storage
5℃±3℃ 0,1,3,6,9,12 months 12 months
Accelerated experiment
25℃±2
0,1,3,6 months 6 months
60%±5%RH
6 months


Application:

This compact medical freezer is mainly used to save drugs, reagents, vaccines, biological products and blood products, etc.


Advantages:

Low noise, long life

Easy to clean

High efficiency

High temperature accuracy
